Products	Wireless Video Transmitter
Model age	MBro-WVT	MBro-WVR-T1	MBro-WVR-T2
Dimension	260x260x88mm
Interface	HD-SDI (1ch)	Ethernet
Control	MBro Wireless Control/Application S/W
Set-up	(Option) MBro Easy Set-Up S/W
Radio
Radio Range	Max 3Km (LOS)
Standard	11a/n 2T2R	11a/b/g/n 2T2R	11a/b/g/n 2T2R
MIMO	MIMO
On Board Wi-Fi	x	1	1
On Board Wi-Fi	x	5.15 ~ 5.825G	2.412 ~ 2.472
PCIe Wi-Fi module	1	1	1
PCIe Wi-Fi module	5.15 ~ 5.825G	2.412 ~ 2.472/5.15 ~ 5.825G	5.15 ~ 5.825G
Antenna	MIMO 2T/2R, 17°
System
Chipset	Wireless Video Codec	Qualcomm AR9342	Qualcomm QCA9558
Memory	SDRAM/Flash	SDRAM 64M/Flash 16M	SDRAM 128M/Flash 16M
Ethernet	10/100M 1 Port	10/100M 2 Port	GIGA 2 Port
Input Power	DC: 12~24V	DC: 12~24V or Passive PoE: 24V	DC 12V or Passive PoE 48V / PoE 802.3af
Power consumption	3W	5.5W	8.6W

Products	Wireless Video Receiver
Model age	MBro-WVR-R1	MBro-WVR-R2	MBro-WVR-R3
Dimension	260x260x88mm
Interface	Ethernet
Control	MBro Wireless Control/Application S/W
Set-up	(Option) MBro Easy Set-Up S/W
Radio
Radio Range	Max 3Km (LOS)
Standard	11a/b/g/n 2T2R	11a/b/g/n 2T2R	11a/n 2T2R, 11b/g 2T2R
MIMO	MIMO		MIMO x 2
On Board Wi-Fi	1	1	1
On Board Wi-Fi	5.15 ~ 5.825G	2.412 ~ 2.472	2.412 ~ 2.472
PCIe Wi-Fi module	1	1	1
PCIe Wi-Fi module	2.412 ~ 2.472/5.15 ~ 5.825G	5.15 ~ 5.825G	5.15 ~ 5.825G
Antenna	MIMO 2T/2R, 17°	MIMO 2T/2R, 60°	MIMO 2T/2R, 17°
System
Chipset	Qualcomm AR9342	Qualcomm QCA9558	Qualcomm QCA9558
Memory	SDRAM 64M/Flash 16M	SDRAM 128M/Flash 16M
Ethernet	10/100M 2 Port	GIGA 2 Port
Input Power	DC: 12~24V or Passive PoE: 24V	DC 12V or Passive PoE 48V / PoE 802.3af
Power consumption	5.5W	8.6W	8.6W
